PRODUCT PARAMETES

• Water tightness: 700pa
• Air tightness: 1.2m³/(m·h)
• Wind pressure resistance: 5Kpa
• Sound insulation performance: 35dB
• U-Factor(U.S./1-P): 0.38
• SHGC: 0.22

• Glass:Double Tempered Glass with argon ags
  8mm+21A+8mm
  (PVDF Aluminum Strip Between double glass)
• Profile: 6063-T5 aluminum profile
• Profile Thinckness: Frame 2.5mm , door leaf 3.0mm
• Frame Width: 129mm
• Handle: Guangqi comes with its own armrest design
• Hardware: Customized central axis accessories
• Opening Way: Rotate and open horizontally
• Sealing Material: EPDM rubber strip
• Available Size:
  Central axis door Opening Panel
  ( Width:900-2700/Height:2350-4500)
  Pivot door Opening Panel
  ( Width:900-1350/Height:2350-4500)"

PRODUCT PROCESS

Adopting internal and external gluing process
