PRODUCT PARAMETES

• Water tightness: 350pa; 450pa
• Air tightness: 1.8m³/(m·h)
• Wind pressure resistance: 4.5Kpa
• Sound insulation performance: 30dB; 35dB
• U-Factor(U.S./1-P): 0.38
• SHGC: 0.22

• Glass:Double Tempered Glass with argon ags
  5mm+27A+5mm;
  5mm+20A+5mm;
  (PVDF Aluminum Strip Between double glass)
• Profile: 6063-T5 aluminum profile
• Profile Thinckness: 1.6mm; 2.0mm
• Frame Width: 78mm; 80mm
• Handle: Kerssemberg / CMECH Handle in Black or Slive
• Higne: Kerssemberg / CMECH Hinge in Black or Sliver
• Lock Point Kerssemberg / CMECH Specialized locking point
• Insulation Strip: Standard BAIYUNYILE insulation strip
• Optional Package: New 47 Pack/70 Pack/75 Pack/100 Pack
• Sealing Material:
  EPDM rubber strip;
  JIANGYINHAIDA rubber strip
• Available Size:
  Opening Panel ( Width:500-800/Height:1000-2800);
  Opening Panel ( Width:500-850/Height:1000-3000)

PRODUCT PROCESS

Adopting internal and external gluing process
